Ultra Precision High Q Air Core Inductor 99.99% OFC Copper Coil For Audiophile Speaker Crossover RFID Sensors
US$0.50-1
/pieces
Price varies depending on material, logo, quantity and customization requirements.
Quality You Can Trust
Flexible & Scalable Solutions
Customizable Product Options
Comprehensive Specifications
Your Reliable Business Partner
Category:
Other Copper Products
Introduction
| Type | Edgewise Winding / Flat-wise Winding Inductor | Mounting Type | Bolt-on / Custom Solder Leads |
| Function | HF Filtering / Resonance / Energy Storage | Supplier Type | Manufacturer Direct Supply |
| Q @ Freq | High Q-factor: > 80 | Application | High-power Inverters / EV Charging Piles |
| Rated Power | 100W - 5000W (Size dependent) | Mfg. Date Code | 20260101-20561230 |
| Cross Reference | Custom-made Parts | Tolerance | Inductance Tolerance ±5% or ±10% |
| Operating Temperature | -40℃ to +180℃ (Class H) | Package Type | Open-frame Custom Packaging |
| Resistance Tolerance | Resistance Error ±5% | Temperature Coefficient | 3930 ppm/K (Pure Copper) |
| Resistance | 0.2mΩ - 5.0mΩ(DCR) / Frequency Dependent | Media Available | Datasheet / Drawings / RoHS |
| Frequency - Self Resonant | Self-resonant Frequency (SRF) > 1 MHz | Features | High Current/ Ultra-low DCR/ High Heat Dissipation |
| Height - Seated (max) | Customized / 10-50mm (Turns dependent) | Inductance | Customized / 1μH - 100μH |
| Package / Case | Bare Coil / Varnish Impregnated | Size / Dimension | Outer Diameter: 20mm - 120mm |
| Heigh | Customized / 5mm - 100mm | Number of Coils | Customized / 3T - 200T |
| Inductance - Connected In Parallel | Customized / 1μH - 100μH | Inductance - Connected In Series | Customized / 1μH - 100μH |
| Current Rating - Parallel | Customized / 20A - 200A | Current Saturation - Parallel | No Saturation (Air core does not saturate) |
| Current Saturation - Series | No Saturation (Air core does not saturate) | DC Resistance (DCR) - Parallel | 0.2mΩ - 5.0mΩ |
| DC Resistance (DCR) - Series | 0.2mΩ - 5.0mΩ | Shielding | Non-shielded |
| Material - Core | None / Ferrite / Mn-Zn / Ni-Zn / Sendust (Kool Mu) | Current Rating (amps) | 20A - 200A |
| Current - Saturation | 20A - 200A | DC Resistance (DCR) | 0.2mΩ - 5.0mΩ |
| Mounting Type & Terminal Style | Support Surface Mount, Through Hole, and DIP Pin Installation | Safety & Environmental Certification | Fully CE Certified and RoHS Compliant for International Standards |
| Electromagnetic Shielding Options | Available in Shielded, Unshielded, and Customized Shielding Case) | Primary Application Field | Optimized for Wireless Transmitter Application and For Receiver Use |
| Lead Configuration Design | Professional Radial Leaded Wire Design for Secure PCB Mounting | Logistics & Customized Packing | Customized Packing in Tape & Reel or Protective Bulk Export Box |
| Conductor Material & Structure | High Quality Enameled Copper Wire and Customized Flat Winding Coil | High Frequency Performance | High Q Factor, Low Loss and High Heat Dissipation for HF Circuits |
| OEM ODM Customization Service | Fully Customized Shape, Size and Inductance Based on User Drawings | Export Packaging Compliance | EPR France Packing Certified and German EPR Packaging Standards |
